Product Type: PSC (Permanent Split Capacitor)

HP: 2

RPM: 3450

Volts: 230

Amps: 10

Hz: 60

Phase: 1

Frame: 56Y

Enclosure Type: ODP (Open Dripproof)

Mounting: Square Flange

Rotation: CCW Pump End

Number of Speeds: 1

Service Factor (SF): 1.10

Bearings: Ball

Thermal Protection: Automatic

Maximum Ambient Temperature: 50° C

Insulation Class: B

Duty Cycle: Continuous

Capacitor: Included

Motor Diameter: 6-1/2"

Overall Length (including shaft): 13.46"

Body Length (less shaft): 9"

Shaft Dimensions: 1/2 x 0.91" threaded

Frame Material: Rolled Steel

"1081" Design
